The VadaTech UTC040C is the most feature-rich conduction cooled MicroTCA Carrier Hub (MCH) in the market. Its management software is based on VadaTech’s robust Carrier Manager and Shelf Manager which have been deployed for years with proven results. It also manages PCIe Gen3 Switch as well as the GbE Switch
.The UTC040C runs Linux on its centralized quad-core CPU and is hot-swappable/fullyredundant when used in conjunction with a second instance of the module.
The firmware is HPM.2 compliant which allows for easy upgrades. It provides Master JTAG services to the AMCs via the JSM.
Key Features
ØDouble module, mid-size per AMC.0
ØConduction cooled for rugged applications
ØUnified 1GHz quad-core CPU for MCMC (MicroTCA Carrier Management Controller), Shelf Manager, Clocking, and Fabric management
ØLayer 2/3 managed GbE Switch
ØFront panel provides 12 ports of GbE
ØNon-blocking PCIe Gen3 Switch with up to four PCIe Virtual Domains
