The AMC348 is a VadaTech low cost AMC graphic module. Designed to meet the graphics needs of Military, Industrial and Telecom applications that requires a simple graphic interface.
The board features Silicon Motion’s SM750 graphics processor chipset. The display mode supports screen resolutions up to 1920x1080 @ 60 Hz for dual mode monitor.
The AMC348 is AMC.1 compliant and is available in a single module, mid or full-size form factor. The front panel has an LHF style connector (DMS-59).
Key Features
ØBased on Silicon Motion’s SM750 graphics processor chipset
ØProvides two separate Dual DVI Channels
ØAMC.1 compliant
ØPCIe x1 lane
ØSingle module, mid-size or full-size (see ordering options)
Ø16MB of Memory
ØDisplays 1920x1080 @ 60 Hz
ØOptional “Y” adapter cable to convert the DMS-59 connector to DVI-I or VGA connectors
ØIPMI 2.0 compliant
ØRoHS compliant
