The AMC723 is a Processor AMC (PrAMC) in a single module, mid size AdvancedMC™ (AMC) form factor based on the Intel® Corei Processor with Cave Creek PCH.
The module follows the AMC.2 and the AMC.3 specifications. It provides PCIe on ports 4-7 (AMC.1) and 10GbE on ports 8-11 per AMC.2, dual GbE on ports 0 and 1 per AMC.2, and SATA on ports 2 and 3 per AMC.3. The module also provides dual GbE to the front.
The AMC723 has option for up to 16 GB of DDR3 memory with ECC and allows for up to 32 GB of Flash for OS. The AMC723 has serial over LAN with hardware Random Number Generator (RNG) as seed generator for authentication.
The BIOS allows booting from on board NAND, off board SATA, PXE boot as well as USB.
Key Features
ØProcessor AMC with Intel® Core i
Øwith Cave Creek PCH
ØSingle module, mid size per AMC.0
Ø(option for full size)
ØPCIe x4 on ports 4-7 (AMC.1)
Ø10GbE XAUI on ports 8-11 (AMC.2)
ØGbE to port 0 and 1 (AMC.2)
ØSATA to port 2 and 3 (AMC.3)
ØDual GbE to the front panel
ØUp to 16GB of DDR3 memory with ECC
ØOption for up to 32GBytes of Flash
ØSerial over LAN
ØIPMI 2.0 compliant
